Lucette G2, Ø120 mm230VAC - 7.5W - 3000K / 4000K CCT switch

Item no.: 38101013

EAN: 5704629004931

	Choose size

Amount

Buy

Copy EAN number 5704629004931

Product information
Download

Approved for installation directly in insulation and
flammable materials
Dimmable
High colour rendering index – CRI>90
High lumen output
Flicker free according to the latest Ecodesign / ErP directive
CCT switch 3000K / 4000K
3-pole levers in the connector box
Quick and easy mounting with springs
For indoor and outdoor use

Product Information Sheet

Manual

Technical data for Lucette G2, Ø120 mm

Voltage	220-240 VAC 50/60 Hz
System effect	7.5W
Light source	LED
Colour temperature	3000 / 4000 Kelvin CCT switch
Light intensity	500 / 550 Lumen
Colour rendering	CRI>90
Expected lifespan	50,000 hours L80B10
Dimmable, how	Yes, trailing edge
Flicker free	Yes, according to the latest Ecodesign / ErP directive
SVM <0.4	Yes
PstLM <1	Yes
Beam angle	110°
Cut out	Ø105 mm
Installation height / headroom above ceiling	22 mm / 26 mm
Exterior dimension	Ø120 mm
Dimension driver	L: 71 mm, B: 44,5 mm, H: 26 mm
Dimension connector box	L: 62.5 mm, W: 44 mm, H: 26 mm
Possibility of through wiring	Yes, 2 x 3G1.5 mm²
IP rating, front / back	IP44 / IP20
Insulation class	Class II
Material	Aluminium, plastic
Environment	Indoor and outdoor
Warranty, product / surface	5 years / 10 years
Approvals	CE
