Uni Install excl. light source230VAC

Discontinued

Item no.: 1221-m

EAN:

	Choose environment

	Choose colour

	Choose shape

Amount

Buy

Copy EAN number

Product information
Download

Approved for installation directly in the insulation and flammable materials
Low mounting depth
Quick and easy mounting
Mounting with screws or adjustable springs
Screwless terminal block in the connector box
Possibility of mounting with cable or 16 mm flex tube
Adjustable springs for ceiling thickness up to 44 mm
Adjustable screws for ceiling thickness up to 35 mm
Designed and developed in Denmark

Product Information Sheet

Manual

Technical data for Uni Install excl. light source

Voltage	220-240VAC 50 Hz
System effect	Max. 7.5W LED
Carving dimensions	Ø75 mm
Installation height	63 mm
Exterior dimensions	Ø87 mm
Dimensions connector box	L: 85 mm, W: 55 mm, H: 30 mm
Tilt angle	30°
Possibility of through wiring	Yes, 3G1.5
IP-class	IP44 (depends on the light source)
Insulation class	Class II
Material	Aluminium, plastic
Environment	Indoors
Warranty	5 years
Approvals	CE
